Description
• A range of industrial 500kg capacity medium duty workbenches ideal for workshops and assembly areas
• Workbenches can be made to suit customer specifications
• Supplied KD for easy assembly
• All benches are 840mm high and can be bolted to the floor
• Workbenches available in 600mm, 750mm and 900mm
• Drawer and cupboards are supplied in either light grey, green, blue or red.
• Workbenches powder coated in grey and available in a range of worktops: 2mm thick steel, 18mm thick laminate, 18mm thick vinyl, 18mm thick plywood and 24mm thick mdf
Additional available accessories: steel retaining lip 100mm high, cupboard, combi cupboard & drawer, 1,2 and 3 drawer units, electric service duct, support rails 1500mm high, flourescent light, upper shelves and base shelves, and louvered back panel
Specification
.tg {border-collapse:collapse;border-spacing:0;}
.tg td{border-color:black;border-style:solid;border-width:1px;font-family:Arial, sans-serif;font-size:14px;
overflow:hidden;padding:10px 5px;word-break:normal;}
.tg th{border-color:black;border-style:solid;border-width:1px;font-family:Arial, sans-serif;font-size:14px;
font-weight:normal;overflow:hidden;padding:10px 5px;word-break:normal;}
.tg .tg-lboi{border-color:inherit;text-align:left;vertical-align:middle}
.tg .tg-yj5y{background-color:#efefef;border-color:inherit;text-align:center;vertical-align:top}
.tg .tg-c3ow{border-color:inherit;text-align:center;vertical-align:top}
.tg .tg-4px2{background-color:#680100;border-color:inherit;color:#ffffff;text-align:center;vertical-align:top}
.tg .tg-y698{background-color:#efefef;border-color:inherit;text-align:left;vertical-align:top}
.tg .tg-c6of{background-color:#ffffff;border-color:inherit;text-align:left;vertical-align:top}
.tg .tg-3xi5{background-color:#ffffff;border-color:inherit;text-align:center;vertical-align:top}
.tg .tg-7btt{border-color:inherit;font-weight:bold;text-align:center;vertical-align:top}
| 500KG MEDIUM DUTY WORKBENCHES |
| Worktop material/ thickness |
Steel 2mm |
Laminate 18mm |
Vinyl 18mm |
Plywood 18mm |
MDF – 24mm |
| Length |
Width |
Type |
Type |
Type |
Type |
Type |
| 1200mm |
600mm |
1240w |
1249w |
1258w |
1267w |
1276w |
| 750mm |
1241w |
1250w |
1259w |
1268w |
1277w |
| 900mm |
1242w |
1251w |
1260w |
1269w |
1278w |
| 1500mm |
600mm |
1243w |
1252w |
1261w |
1270w |
1279w |
| 750mm |
1244w |
1253w |
1262w |
1271w |
1280w |
| 900mm |
1245w |
1254w |
1263w |
1272w |
1281w |
| 1800mm |
600mm |
1246w |
1255w |
1264w |
1273w |
1282w |
| 750mm |
1247w |
1256w |
1265w |
1274w |
1283w |
| 900mm |
1248w |
1257w |
1266w |
1275w |
1284w |
| OPTIONAL EXTRAS |
| Description |
Size |
Type |
| Steel Retaining Lip |
1200mm |
1312w |
| 1500mm |
1313w |
| 1800mm |
1314w |
| Cupboard |
450 x 450 x 610mm |
1315w |
| Combi Cupboard & Drawer |
450 x 460 x 610mm |
1316w |
| Drawer units – 25kg udl |
1 Drawer |
1317w |
| 2 Drawer |
1318w |
| 3 Drawer |
1319w |
| Electric Service Duct |
1200mm |
1320w |
| 1500mm |
1321w |
| 1800mm |
1322w |
| Support Rails 1500mm high |
Pair |
1323w |
| Louvered back panel (bins not included) |
1200mm |
1324w |
| 1500mm |
1325w |
| 1800mm |
1326w |
| Fluorescent light |
1200mm |
1327w |
| 1500mm |
1328w |
| 1800mm |
1329w |
| Upper Shelf – Steel |
1200mm |
1333w |
| 1500mm |
1334w |
| 1800mm |
1335w |
| Base Shelf -Steel |
1200mm |
1336w |
| 1500mm |
1337w |
| 1800mm |
1338w |
