Economy Manual Mobile Double Scissor Lift Tables



Price on application

Category:

Description

Mobile scissor table range has been designed, developed and built to give long service with minimum maintenance required.

– Manual hydraulic operation
– Can be used safely at any height
– Fitted with two total stop brakes as standard to prevent the table from moving when loading and unloading.
– All models fitted with an overload valve
– Hard wearing and non-marking polyurethane tyres prevent damage to floors.
– Swivel wheels fitted with thread guards
– Epoxy powder coated finish for durability
– Issued with a test certificate in conformance with EU standard EN 1570.



Please note:  colour/appearance may differ from images shown

Specification

.tg {border-collapse:collapse;border-spacing:0;} .tg td{border-color:black;border-style:solid;border-width:1px;font-family:Arial, sans-serif;font-size:14px; overflow:hidden;padding:10px 5px;word-break:normal;} .tg th{border-color:black;border-style:solid;border-width:1px;font-family:Arial, sans-serif;font-size:14px; font-weight:normal;overflow:hidden;padding:10px 5px;word-break:normal;} .tg .tg-baqh{text-align:center;vertical-align:top} .tg .tg-amwm{font-weight:bold;text-align:center;vertical-align:top}
Type Capacity Minimum
Table Height 		Maximum
Table Height 		Table W x L Handle Height Wheel Dia No of strokes
to full height 		Nett weight
8422w 150kg 310mm 1120mm 450 x 700mm 920mm 100mm 30 47kg
8423w 150kg 435mm 1450mm 500 x 830mm 1050mm 150mm 31 91kg
2529w 350kg 335mm 1300mm 500 x 910mm 975mm 125mm 53 105kg
8424w 680kg 475mm 1510mm 610 x 1010mm 1020mm 150mm 70 176kg
8425w 800kg 485mm 1500mm 610 x 1210mm 970mm 150mm 90 181kg
