Description
• Robust construction
• Ergonomic pump handle
• Separate tiller handle
• Safety valve prevents overloading
• Fitted with chain link steering for easy operation
Price on application
• Robust construction
• Ergonomic pump handle
• Separate tiller handle
• Safety valve prevents overloading
• Fitted with chain link steering for easy operation
Type | 9728w | 9729w | 9730w | 9731w | 9732w |
Capacity | 1000kg | ||||
Load Centre | 600mm | ||||
Max. Lift Height | 1120mm | 1600mm | 2000mm | 2500mm | 3000mm |
Lowered Fork Height | 85mm | ||||
Fork Length | 1150mm | ||||
Width over Forks | 545mm | ||||
Overall Length | 1785mm | ||||
Overall width | 665mm | 665mm | 775mm | 775mm | 775mm |
Overall Closed Height | 1585mm | 1970mm | 1470mm | 1720mm | 1970mm |
Mast Type | Single | Single | Duplex | Duplex | Duplex |
Wheels | ø 200mm Polyurethane / ø 80mm Nylon | ||||
Approx. Weight | 230kg | 250kg | 300kg | 340kg | 380kg |
