Description
Access Platforms provide a safe environment for a wide range of maintenance and inspections to be carried out from, with the reassurance that they have been manufactured in accordance with HSE document PM28 4th Edition.
Standard Features
• Hinge back guard for ease of transportation and storage
• Safety harness attachment rings
• Self-draining non-slip floor
• Internal Handles
• Stilt pressings to elevate fork pockets
• Zinc plated heel pins for safe attachment to truck
• Maximum fork section 150 x 50 mm at 525 centres
• Painted bright orange for safety
Optional Features
• Safety harness
Specification
.tg {border-collapse:collapse;border-spacing:0;}
.tg td{font-family:Arial, sans-serif;font-size:14px;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;border-color:black;}
.tg th{font-family:Arial, sans-serif;font-size:14px;font-weight:normal;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;border-color:black;}
.tg .tg-c3ow{border-color:inherit;text-align:center;vertical-align:top}
.tg .tg-7btt{font-weight:bold;border-color:inherit;text-align:center;vertical-align:top}
| Capacity |
C of G |
No of Persons |
Personal Access |
Platform base size
L x W x H |
Weight |
Type |
| 250kg |
330mm |
2 |
lift-up-bar |
1500 x 950 x 2120mm |
141kg |
9614w |
| 250kg |
330mm |
2 |
lift-up-bar |
1800 x 950 x 2120mm |
155kg |
9615w |
